Ponte Giulio Bathtub Folding Bench with HPL Top - G25JDS18 / G25JDS19 (450 lb Capacity, ADA Compliant)

Ponte Giulio Bathtub Folding Bench with HPL Top - G25JDS18 / G25JDS19 (450 lb Capacity, ADA Compliant)

SKU: G25JDS18

Price: $505.60
List Price:
Price: $505.60
10% off | Coupon Code: AIDE | Ends:
View Cart

The Ponte Giulio Bathtub Folding Bench with HPL Top (Series SKUs: G25JDS18 & G25JDS19) is a commercial-grade, wall-mounted bathtub seating solution engineered specifically for alcove tub configurations, universal design residential developments, and commercial ADA-compliant rest areas. Designed to span across standard tub enclosures, this folding bench combines a 10 mm thick High Pressure Laminate (HPL / Phenolic) seat surface with a heavy-duty stainless steel internal chassis. The structural frame is enclosed in a warm-touch antimicrobial vinyl coating incorporating BioCote® silver ion technology. An integrated internal tension hinge controls the folding motion, securing the bench flat against the wall when stowed.

Technical Specifications

System Attribute Specification Parameter Standard & Material Compliance
Model SKUs G25JDS18 (27" Nominal) / G25JDS19 (31" Nominal) Ponte Giulio Tracked Product SKUs
G25JDS18 Envelope (D x W x H) 18.75" Depth x 27.19" Width x 5.13" Height Engineered for 28" to 30" Standard Tubs
G25JDS19 Envelope (D x W x H) 18.75" Depth x 31.13" Width x 5.13" Height Engineered for 30" to 32" Standard Tubs
Seating Depth Surface 16.0 Inches (15.94" / 405 mm Actual) Standard Bathtub Transfer Footprint
Mounting Flange Height 5.0 Inches (5.13" / 130 mm Overall Profile) Heavy-Duty Wall Anchorage Plates
Seat Top Material & Finish 10 mm High Pressure Laminate (HPL / Phenolic) Non-Porous White with Speckles Top (W8/N1)
Frame Core & Coating AISI 304 Stainless Steel Core + 3mm Vinyl Corrosion-Resistant Structural Core Assembly
Hygiene Technology BioCote® Silver Ion Antimicrobial Coating Inhibits Bacterial Growth up to 99.9%
Hinge Mechanism Controlled Friction Tension Hinge Prevents Uncontrolled Bench Dropping
Vertical Static Load Rating 450 lbs (204.5 kg Vertical Static Load Capacity) Exceeds ADA 250-lb Structural Requirement
Net Weight G25JDS18: 14.99 lbs | G25JDS19: 15.43 lbs Solid Heavy-Duty Unit Construction
Included Hardware Stainless Steel Fasteners Included Supplied for Structural Wood Stud Mounting
Regulatory Standard ADA / ANSI A117.1 Compliant Federal Accessibility Standard Certified

Key Performance & Construction Features

  • 450-Pound Vertical Static Load Rating: Engineered for structural rigidity, allowing the bench platform to span across standard bathtub alcoves while meeting commercial accessibility standards.
  • BioCote® Silver Ion Antimicrobial Protection: Integrated directly into the 3 mm exterior vinyl coating, BioCote® technology permanently inhibits the growth of bacteria, molds, and fungi by up to 99.9%.
  • 10mm High-Pressure Laminate (HPL) Top: The non-porous, warm-touch phenolic surface in White with Speckles resists scratching, impact, mold, and harsh sanitation chemicals.
  • Internal AISI 304 Stainless Steel Frame: The structural skeleton is fabricated from 304-grade stainless steel to ensure complete rust resistance in wet environments.
  • Controlled Friction Tension Hinge: Features an internal friction-hinge mechanism that holds the bench flat against the wall tile when stowed and controls the pivot motion during deployment.
  • Dual Tub Width Sizing: Available in 27-3/16" width (fitting 28"–30" tubs) and 31-1/8" width (fitting 30"–32" tubs) for precise installation across various alcove dimensions.
  • Wood Stud Mounting Package Included: Supplied complete with heavy-duty structural mounting hardware for direct structural wood stud or wall blocking installation.

Regulatory Compliance & Installation Notes

To ensure full ADA and building code compliance:

  • ADA Compliance: When mounted securely into solid wood studs or approved structural wall blocking at the correct height, this bathtub bench meets federal ADA specifications for bathtub seating and load capacity.
  • Structural Anchoring Requirement: Wall mounting flanges must be anchored directly into solid wood studs or structural wall blocking capable of supporting the rated 450-pound vertical static load.

Shipping, Stock Status, and Returns

In accordance with our commitment to consumer transparency and Google Merchant Center compliance:

  • Availability: In Stock and ready to ship. Processing lead time is 1–2 business days.
  • Shipping Costs: Calculated in real-time during checkout based on delivery destination and total order weight. No hidden handling fees.
  • Refund & Return Policy: Covered under our 30-Day Policy. If the product arrives damaged, is lost in transit, or is the incorrect SKU, contact customer support at support@universalaide.com for an immediate exchange or full refund.
