Ponte Giulio Removable and Folding Support Grab Bar with Integrated Paper Holder - G19JCS11 / G19JCS12 / G19JCS13 (ADA Compliant)

Ponte Giulio Removable and Folding Support Grab Bar with Integrated Paper Holder - G19JCS11 / G19JCS12 / G19JCS13 (ADA Compliant)

SKU: G19JCS11

Price: $604.40
List Price:
Price: $604.40
10% off | Coupon Code: AIDE | Ends:
Length
View Cart

The Ponte Giulio Removable and Folding Support Grab Bar with Integrated Paper Roll Holder (Series SKUs: G19JCS11, G19JCS12, & G19JCS13) is a commercial-grade, multi-length wall-mounted support rail engineered specifically for water closet installations, flexible residential layouts, universal design developments, and commercial ADA-compliant restrooms. Featuring an integrated paper roll spindle attached directly to the upper rail chassis, this unit combines a 40 x 25 mm rectangular top arm (1.5 mm wall thickness) with a 26.9 mm diameter lower reinforcing support tube in AISI 304 stainless steel. The engineered dual-flange aluminum quick-release system allows the entire rail assembly to be easily detached from the wall plate when not required, leaving a clean wall profile that can be capped with an optional escutcheon plate cover.

Technical Specifications

System Attribute Specification Parameter Standard & Material Compliance
Model SKUs G19JCS11 (24" Nominal) / G19JCS12 (28" Nominal) / G19JCS13 (33" Nominal) Ponte Giulio Tracked Product SKUs
G19JCS11 Envelope (W x L x H) 4.31" Width x 23.62" Length x 7.63" Height Rough-In Envelope (4-5/16" x 23-5/8" x 7-5/8")
G19JCS12 Envelope (W x L x H) 4.31" Width x 27.56" Length x 7.63" Height Rough-In Envelope (4-5/16" x 27-9/16" x 7-5/8")
G19JCS13 Envelope (W x L x H) 4.31" Width x 33.44" Length x 7.63" Height Rough-In Envelope (4-5/16" x 33-7/16" x 7-5/8")
Integrated Roll Holder Stainless Steel Paper Roll Spindle Attachment Built Directly Into Top Arm Chassis
Top Arm Section Profile 40 x 25 mm Rectangular Tube (1.5 mm Wall Thickness) Heavy-Duty Upper Structural Rail
Lower Reinforcing Support Tube Ø 26.9 mm Round Tube (1.5 mm Thickness) AISI 304 Stainless Steel Satin Stainless Steel Support (N1 Finish)
Mounting Plate Profile 7.63" Height x 4.31" Width (7 5/8" x 4 5/16") Heavy-Duty Extruded Aluminum Disconnect Base
Escutcheon Cover & Pivot Cylinder High-Impact ABS Synthetic Polymer Concealed Fastener Protective Escutcheon
G19JCS11 & G19JCS12 Static Load Rating 331 lbs (150 kg Vertical Static Load Capacity) Exceeds ADA 250-lb Structural Requirement
G19JCS13 Static Load Rating 265 lbs (120 kg Vertical Static Load Capacity) Exceeds ADA 250-lb Structural Requirement
Net Tare Weight G19JCS11: 5.82 lbs | G19JCS12: 6.08 lbs | G19JCS13: 6.35 lbs Solid Commercial Unit Construction
Anchoring Requirements Mount Direct to Structural Wood Studs or Blocking Fasteners Selected per Specific Substrate Type
Regulatory Standard ADA / ANSI A117.1 Compliant Federal Accessibility Standard Certified

Folding and removable support, with roll paper holder, 600 mm

Folding and removable support, with roll paper holder, 700 mm

Folding and removable support, with roll paper holder, 850 mm

Key Performance & Construction Features

  • Integrated Toilet Paper Spindle: Incorporates a functional paper roll holder directly onto the structural top arm, optimizing fixture utility near water closets while satisfying ADA reach parameters.
  • Quick-Release Removable Wall Anchorage System: Features an interlocking aluminum mounting plate assembly that permits full removal of the support bar from the wall plate for storage or spatial adaptability.
  • Dual-Tube Structural Reinforcement Architecture: Combines a 40 x 25 mm upper rectangular arm with a lower 26.9 mm round AISI 304 stainless steel diagonal brace to deliver high vertical load resistance.
  • High Vertical Static Load Ratings: Tested to support up to 331 lbs vertical static load (G19JCS11 & G19JCS12) or 265 lbs vertical static load (G19JCS13) in commercial and residential facilities.
  • Rust-Proof Stainless Steel & Aluminum Construction: The structural frame, lower diagonal tube, and wall mounting chassis resist internal oxidation and chemical corrosion in high-humidity environments.
  • Concealed ABS Mounting Plate Escutcheon: The 7.63" x 4.31" aluminum wall base is enclosed beneath a high-impact ABS cover plate to shield fasteners from direct water exposure.
  • Space-Saving Vertical Fold Profile: Rotates upward flat against the wall tile when stowed, maximizing lateral transfer space inside the restroom area.

Regulatory Compliance & Installation Notes

To ensure full ADA and building code compliance:

  • ADA Compliance: When mounted securely into solid wood studs or structural wall blocking at the correct height adjacent to a water closet, this folding support bar meets federal ADA specifications for accessible support rails and paper dispenser reach ranges.
  • Structural Anchoring Requirement: Mounting hardware is not supplied with this fixture. Fasteners must be selected by a qualified installer based on wall backing composition (e.g., solid wood studs or structural blocking) capable of supporting the rated vertical static load capacity.
